30A MPPT Solar Charge Controller

Overview Technology Specifications Parameter

30A MPPT Solar Charge Controller

Retail price:

699

12V/24V/36V/48V DC Selectable

Battery Type Selectable, Lithium Battery Supported

Charging Current: 30A/60A/80A

MPPT Tracking Efficiency Up to 99.9%

Circuit Energy Conversion Efficiency Up to 98%

Charging Features Active Voltage Regulation

Temperature Compensation Function

Advanced Current-Limiting Charging Mode

Contact immediately

MPPT Solar Charge Controller

Mix & Match Freely | Multiple Safety Protections | Superior Experience

Compatible with RV Solar Systems

98% Efficient Conversion | Precise Tracking, Intelligent Charging

Automatic Identification System

Auto-Charging Mode Switch | Anti-Overcharge, Longer Battery Life

Multi-Battery Compatible

Deep-cycle Sealed Lead-Acid,
Flooded, Gel, Lithium Batteries, etc.

PV Module Input

Max PV Module Voltage (VOC)

135V（-20℃） 145V（25℃）

System Voltage

12/24/48V Auto ；36V Set

MPPT Voltage Range

Recommended Max PV Module Input Voltage

22V/40V/60V/80V

Number of MPPT Trackers

PV Module Output

12V

400W

24V

800W

36V

1200W

48V

1600W

Charging Output

Max Output Current

30A

Rated Load Current

20A

Max Capacitive Load Capacity

10000uF

Ripple Voltage

＜0.5%

Applicable Battery Types

Sealed Lead-Acid Battery / Gel Battery / Flooded Battery / Lithium Battery

Specification

No-Load Loss

＜1.5W

Operating Temperature

-20℃~45℃

Size

238*180*90mm

Net Weight

2.3KG

IP Rate

IP20
